Kiloview E1 Wired H.264 HD SDI to IP Live Streaming Encoder
Kiloview E1 H.264 live video encoder delivers H.264 SDI video to various platforms like live broadcasts, Youtube Live, Facebook and live broadcast audio and video encoding for Ustream, Livestream, Twitch, Meridix, Streamspot, Dacast, and more. Applications of the SDI encoder include hotel TV system, school teaching, live broadcasting, church streaming. E1 encoder has approved by CE,FCC,ISO,etc..
H.264 video encoding
Full live platforms supported
Low bandwidth transmission
1080p HD live broadcast
High bandwidth adaptability, makes it possible to transmit highdefinition, low-latency, non-padding image under low bit network.
- With branded chips solution together with video dynamic noise reduction and image enhancement technology, it can realize good encoding
image under low bit transmission. Good video image can be achieved at 1Mbps@720p, 1.5Mbps@1080p network.
- Advanced video buffering technology and FEC technology ensures video encoding delay ≤ 67ms andstable and smooth transmission.
- Adjustable bit rate from 64kbit/s～40Mbit/s.
★Note: (≤67ms) refers to the delay of the encoder end, and the end-to-end delay also relates to network, decoding, etc.
Powerful streaming media service function, supports RTSP/RTMP/TS/Onvif/SIP/GB/T281 and some other protocols.
- RTP/ RTSP/ RTMP/ SRT/ HLS/ TS/ Onvif/ SIP and some other streaming media protocols supported for live broadcast on Facebook, YouTube, Ustream, Twitch, Wowza etc or security platform/ NVR system.
- Dual stream output, the main code rate up to 1080p60Hz, and the sub-stream supports 720p 60Hz video encoding.
Portable size, image and characters overlay supported with functions of voice intercom, NAS storage, loop monitoring etc.
- Portable and low power consumption makes it 24 hours continuous working available.
- Capable with customized text and image overlay function, which can be at any position on the screen.
- Audio embedding encoding supported, with voice intercom function (need to deploy voice.intercom software).
- Supports NAS network storage.
- With video real-time loop function, there is no delay and convenient for live monitoring.
Strong flexibility to support secondary development, customized service available
- Open API programming, SDK provided for second development;.
- Customization service available based on client’s needs.
Analog audio input
Analog audio output
2*USB 2.0 Type-A; 1*USB 2.0 Mini-USB
1*Micro SD/TF Card storage interface
Up to 1080P60Hz, details as follows: 1080p23.98/24/25/29.97/30Hz 1080p50/59.94/60Hz 1080i50/59.94/60Hz 720p23.98/24/25/29.97/30Hz 720p50/59.94/60Hz, 576i, 480i 720*480(NTSC)，720*576(PAL)
